Online-Offline Dissolution System

Features:

• Most flexible configuration, since it allows online, offline as well as online and offline operation
• Cross verification of the sample can be performed using the balance sample in the collector
• A wide range of dilutions of up to 1:100 is achievable in combination with the path length of the flow through cells and dilution via the sample collector

Features of Syringe Pump (Model: ESP-84)

1. Performs key operations like diluting and mixing samples up to 1:25, filtering, storing and replacing withdrawn samples with fresh media
2. The glass/Teflon syringes eliminate adsorption and offer a high accuracy of dosing (better than +/- 1 %)
3. No routine calibration or maintenance
4. Supports 10 ml and 25 ml syringes
5. The high suction capability enables efficient use of fine inline disk type syringe filters (0.45 microns) eliminating manual filtration process
6. The 4-way motorized valve offers unprecedented system flexibility and the capability to deal with sticky media
7. The ergonomically designed syringe pump has a very small footprint to save bench space

Features of Sample Collector (Model: ESC-08)

1. The x-y arm movement meets all the automated sampling requirements such as collecting, mixing, aspirating and diluting the samples
2. The diving mechanism pierces the septas of vials to prevent evaporative losses
3. Special sensor detects the alignment and type of tray used to prevent any human errors
4. Completely covered to prevent contamination and air drafts which cause excess eveporation of the collected samples
8 Stn Online-Offline Dissolution System with Syringe Pump, Sample Collector & UV Spectrophotometer.
